Tie rod hydraulic cylinders are not as complex in terms of design as welded body cylinders. Tie rod hydraulic cylinders use high-strength threaded steel rods in order to hold the end caps to the cylinder barrel. Small bore cylinders typically have four tie rods whereas larger bore cylinders can have as many as twenty tie rods in order to withstand the forces produced by the cylinder.
Tie rod cylinders have been a go to for most agricultural applications for over 50 years. The hydraulic cylinder is used to transform the hydraulic fluid.
energy into mechanical – output energy of the component. A hydraulic cylinder is a positive displacement motor of reciprocating motion. Hydraulic cylinders are widely used in the mobile and other technological industries. It’s low cost to manufacture and the fact that it isn’t welded makes it affordable for anyone needing a cylinder. Magister threaded double-acting tie rod hydraulic cylinders offer a heavy-duty design, capable of withstanding operating pressure up to 2500 PSI. High tensile honed cold drawn tube for durability. High tensile ground & polished hard chrome plated rod. Ductile iron clevis end mount with screw-on ductile iron clevis mount. Rod seals are composed of high quality U-cup polyurethane with inner O-ring and polyurethane wiper. Bore size available in 2”, 2.5”, 3” up to 24” stroke. Suitable for both single and double acting operations. Excellent for use in a wide range of industries such as agriculture, automotive and transportation, and manufacturing.
